XM 19/Nitronic Round Bar Manufacturers, Suppliers & Exporter in India

Nova Steel Corporation is the best leading XM19/Nitronic Round Bar Manufacturers in Mumbai, India. Its crystalline structure is formed by the addition of three main stabilizing elements i.e. – nitrogen, manganese, and nickel. Nitronic 60 Round Bar demonstrates properties like good mechanical strength, good toughness, and ductility, all of which are characteristics of austenitic stainless steel alloys. Our high-quality range of XM 19/Nitronic Round Bar is exclusively designed for steel factories, petrochemical industry, fire protection systems, chemical industries, shipping/shipment industries, etc.

Nitronic 60 Round Bar Manufacturers, Nitronic 60 Round Bar Suppliers & Exporter in India

Nova Steel Corporation is one of the largest exporter, manufacturers, and supplier of Nitronic 60 Round Bars in India. The oxidation resistance of Nitronic Alloy 60 Rods (Nitronic 60 Rods) is similar to Stainless Steel 309 Grade and far higher to Stainless Steel 304 Grade. This grade is best recognized for its wear and galling resistance. Nitronic 60 is an S21800 stainless steel grade austenitic metal with versatile performance characteristics. We are also the suppliers of LF2 Round Bar, and so on.

Nitronic 50 Round Bar

Nitronic 60 Round Bar

Nitronic Alloy 60 Round Bars Grades & Specification

Dimension: EN, DIN, JIS, ASTM, BS, ASME, AISI

Grade: Nitronic Alloy 60 (UNS No. S21800) Round Bars

Finish: Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish

Form: Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.

Surface: Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline

Application: Chemical process, Food processing, Petrochemical, Pollution control, Pulp and Paper, Refining

Condition: Cold Drawn Published Cold Drawn Centreless Ground & Polished.

Our Nitronic Alloy 60 Round Bars conforms to NACE MR0175/ISO 15156

XM-19 Stainless Steel Bar Chemical Formula

	Ni	Cr	Mo	Mn	Si	C	N	S	P	Cb	V	Fe
MIN	11.5	20.5	1.5	4.0	–	–	0.2	–	–	0.1	0.1	–
MAX	13.5	23.5	3.0	6.0	1.0	0.06	0.4	0.03	0.045	0.3	0.3	Balance

Nitronic 50 Hex Bar Mechanical Analysis

Temperature, °F	-320	-100	75	200	400	600	800	1000	1200	1350	1500
Ultimate Tensile Strength, ksi	–	–	117	107	96	92	89	84	74	66	52
0.2% Yield Strength, ksi	–	–	60	50	38	35	34	32	31	31	30
Elongation, 2%	–	–	45	43.5	43.5	42.5	43.5	41	38	37	41
Impact Strength, ft-lbs	50	115	170	–	–	–	–	–	–	–	–

Physical Component of Nitronic 50 Flat Bar

Temperature, °F	70	200	300	400	600	800	900	1000	1200	1400
Coefficient of Thermal Expansion, in/in°F x 10-6		9.0		9.2	9.6	9.9		10.2	10.5	10.8
Thermal Conductivity Btu • ft/ft2 • hr • °F	108		108		124		141		160
Modulus of Elasticity, psi X 106 STA		26.2
Density: 0.285 lb/inch3
Melting Range: 2579-2642°F
Electrical Resistivity: 492-ohm circ-mil/ft

Equivalent Grades Of UNS S20910 XM-19 Square bar

STANDARD	UNS	JIS
SS Nitronic 50	S20910	SUH 660

Nitronic 50 Stainless Steel Threaded Rod Weight Per Foot

Round Bar
Size	Kgs / Foot	Kgs / Mtr	Size	Kgs / Foot	Kgs / Mtr	Size	Kgs / Foot	Kgs / Mtr
3	0.017	0.055	20	0.753	2.470	3″	10.900	35.762
1/8″	0.019	0.062	22	0.908	2.979	3-1/4″	12.800	41.996
5/32″	0.029	0.095	7/8″	0.926	3.038	3-1/2″	14.850	48.772
4	0.030	0.098	24	1.080	3.543	3-3/4″	17.001	55.780
3/16″	0.043	0.141	25	1.180	3.871	4″	19.306	63.340
5	0.047	0.154	1″	1.210	3.970	4-1/4″	21.908	72.249
7/32″	0.058	0.190	26	1.271	4.170	4-1/2″	24.4487	80.340
6	0.068	0.223	27	1.368	4.490	4-3/4″	27.366	90.249
1/4″	0.076	0.249	1-1/8″	1.534	5.033	5″	30.461	99.940
7	0.091	0.298	30	1.691	5.548	5-1/2″	36.690	121.000
5/16″	0.118	0.387	1-1/4″	1.924	6.349	6″	43.860	143.900
8	0.120	0.398	32	1.894	6.314	6-1/2″	51.093	167.630
9	0.152	0.498	1-3/8″	2.303	7.550	7″	59.432	196.000
3/8″	0.170	0.557	35	2.390	7.553	7-1/2″	68.226	225.000
10	0.189	0.620	36	2.438	7.999	8″	77.586	254.55
11	0.228	0.748	38	2.792	8.903	10″	121.048	397.140
7/16″	0.232	0.761	1-1/2″	2.715	8.951
12	0.271	0.889	40	3.009	9.872
1/2″	0.303	0.994	1-5/8″	3.200	10.449
13	0.318	1.043	1-3/4″	3.712	12.179
14	0.368	1.207	45	3.807	12.555
9/16″	0.383	1.256	1-7/8″	4.260	13.977
15	0.424	1.391	48	4.330	14.205
5/8″	0.473	1.551	50	4.698	15.414
16	0.481	1.578	2″	4.848	15.906
17	0.543	1.791	2-1/8″	5.475	17.963
11/16″	0.573	1.880	2-1/4″	6.135	20.128
18	0.610	2.001	60	6.768	22.205
3/4″	0.682	2.237	2-3/8″	6.838	22.435
			2-1/2″	7.576	24.856
			2-5/8″	8.354	27.409
		2-3/4″	9.169	30.083

DIN 1.3964 Forged Bars Size Inch to MM

Type	SIZES (mm)	SIZES (Inches)	ISO Tolerance
Cold Drawn and Ground	10.00 – 75.00	5/6″ – 2.50″	h8-h9-h10-h11
Peeled and Polished	40.00 – 150.00	1.50″ – 6.00″	h11, h11-DIN 1013
Peeled and Ground	20.00 – 50.00	3/4″ – 2.00″	h9-h10-h11
Cold Drawn and Polish	3.00 – 75.00	1/8″ – 3.00″	h8-h9-h10-h11

Stainless Steel Nitronic 50 Bar Diameter Tolerance

Tolerances for Alloy 50 Rod
Shape / Section	Size, diameter or width across flats	Permitted variation
Shape / Section	milimeter	milimeter
Round	≥6 ≦ 18 > 18 ≦ 30 > 30 ≦ 50 > 50 ≦ 80 > 80 ≦ 100	+ 0 to – 0.070 + 0 to – 0.085 + 0 to – 0.100 + 0 to – 0.120 + 0 to – 0.140
Flat (thickness)	< 18 > 18 ≦ 30 > 30 ≦ 50 > 50 ≦ 80	+ 0 to – 0.110 + 0 to – 0.130 + 0 to – 0.250 + 0 to – 0.350
Flat (width)	< 18 > 18 ≦ 30 > 30 ≦ 50 > 50 ≦ 80 > 80 ≦ 100 > 100 ≦ 130 > 130 ≦ 160 > 160 ≦ 320	+ 0 to – 0.110 + 0 to – 0.130 + 0 to – 0.160 + 0 to – 0.190 + 0 to – 0.220 + 0 to – 0.350 + 0 to – 1.00 + 1.00 to – 1.00
Square and hexagon	≥ 6 ≦ 18 > 18 ≦ 30 > 30 ≦ 50 > 50 ≦ 80 > 80 ≦ 105	+ 0 to – 0.090 + 0 to – 0.110 + 0 to – 0.130 + 0 to – 0.160 + 0 to – 0.250

About Nitronic 60 Round Bar

Nova Steel is the best manufacturers of Nitronic 60 Round Bar are designed and developed in accordance with (International Quality Standards). It offers better chloride pitting resistance, stress corrosion cracking resistance, and crevice corrosion resistance than AISI 316L in laboratory conditions. Hence, the Nitronic 60 Round Bar is classified as an austenitic stainless steel grade. The condition-A variation of stainless steel grade S21800 has been specially processed to increase tensile and yield strength, making it suitable for deployment in conditions where added stability is needed.

Dealers of Nitronic 60 Round Bar

Supplier of Nitronic 60 Round Bar

stockist of Nitronic 60 Round Bar

About XM19/Nitronic Round Bar

Nova Steel is the best manufacturers of XM19/Nitronic Round Bar are designed and developed in accordance with (International Quality Standards). With a yield strength of almost 2 times more than the 300’s series, Nitronic 50 is an austenitic stainless steel alloy. Its crystalline structure is formed by the addition of three main stabilizing elements i.e. – nitrogen, manganese, and nickel. Hence, the Nitronic Alloy 50 Round Bar is classified as an austenitic stainless steel grade.

Dealers of XM19/Nitronic 50 Round Bar

Stockist of XM19/Nitronic 50 Round Bar

Suppliers of XM19/Nitronic 50 Round Bar

ADDITIONAL INFORMATION:

Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer), Other
Port of Dispatch: Mumbai OR KALAMBOLI India
Packaging Details: Fitting are given marking, painted with black japan or black Board (Mat Finish) & will be packed in a bagging bag with stickers written with size, grade & quantity.

Other Related Products:

Clients Project of XM19/Nitronic Round Bar

XM19/Nitronic Round Bar is used in various parts of India. Our company is a name that people trust, our brand name implies fast delivery, affordable prices, and superior quality of XM19/Nitronic Round Bar. Nova Steel Corporation have supplied XM19/Nitronic Round Bar in various cities and in different industries in India. We are therefore known as one of the top-rated XM19/Nitronic Round Bar Suppliers in India.

Product supplied	City
XM19/Nitronic Round Bar for Oil and gas industry	Bareilly, Uttar Pradesh
XM19/Nitronic Round Bar supplied to Pharmaceutical processing industry	Mumbai, Maharashtra
XM19/Nitronic Round Bar supply for Piping	Panaji, Goa
XM19/Nitronic Round Bar supplied to industry	Raipur, Chhattisgarh
