Alloy C-276 Manufacturer, Supplier & Dealer in India.

Nova Steel Corporation is one of the leading Alloy C276 Manufacturer, Supplier,s and Dealer in India. UNS N10276 is a nickel-molybdenum-chromium superalloy with an addition of tungsten designed to have excellent corrosion resistance in a wide range of severe environments. Alloy C-276 is frequently used in many industries, including chemical and petrochemical processing, oil and gas, power generation, pharmaceutical, pulp, and paper production, and wastewater treatment

Alloy C-276 Applicable Specifications

Form	ASTM	ASME	VdTÜV
Bar	B574, B564¹	SB574, SB564¹	400
Plate & Sheet	B575	SB575	400
Welded Pipe	B619	SB619	–
Welded Tube	B626	SB626	–
Seamless Pipe & Tube	B622	SB622

Chemical Composition % Of Alloy C276

Ni	Mo	Cr	Fe	W	Co	Mn	C	V	P	S	Si
Remainder	15.0-17.0	14.5-16.5	4.0-7.0	3.0-4.5	2.5 max	1.0 max	.01 max	.35 max	.04 max	.03 max	.08 max

Mechanical Properties % Of Alloy C276

Product Form	Tensile (ksi)	.2% Yield (ksi)	Elongation %
Bar	110.0	52.6	62
Plate	107.4	50.3	67
Sheet	115.5	54.6	60
Tube & Pipe	105.4	45.4	70

Alloy C-276 Schedule Chart

1/8″ IPS(.405″O. D.)	3 1/2″ IPS( 4.000″O. D.)
SCH 40, 80	SCH 10, 40, 80, 160, XXH
1/4″ IPS(.540″O. D.)	4″ IPS(4.500″O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
3/8″ IPS(.675″O. D.)	5″ IPS( 5.563″O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
1/2″ IPS(.840″O. D.)	6″ IPS(6.625″O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
3/4″ IPS(1.050″O. D.)	8 ” IPS(8.625″O. D.)
SCH 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
1″ IPS:(1.315′O. D.)	10″ IPS(10.750″O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 10, 20, 40, 80 (.500), TRUE 80(.500)
1-1/4″ IPS(1.660″O. D.)	12″ IPS(12.750″O. D.)
SCH 10, 40, 80, 160, XXH	SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
1-1/2″ IPS(1.900″O. D.)	14″ IPS(14.000″O. D.)
SCH 10, 40, 80, 160, XXH	SCH10 (.188), SCH40 (.375)
2″ IPS(2.375″O. D.)	16″ IPS(16.000″O. D.)
SCH 10, 40, 80, 160, XXH	SCH10(.188), SCH40(.375)
2 1/2″ IPS(2.875″O. D.)	18″ IPS (18.000″O. D.)
SCH 10, 40, 80, 160, XXH	SCH-40 (.375)
3″ IPS( 3.500″O. D.)
SCH 5, 10, 40, 80, 160, XXH

Alloy C-276 Seamless Pipe Sizes In Mm

Hastelloy C276 Pipe OD mm	Pipe WT mm	in.	Sch	Kg/m
13.72	1.65	1/4	10S	0.50
13.72	2.24	1/4	40S	0.64
13.72	3.02	1/4	80S	0.81
17.15	1.65	3/8	10S	0.64
17.15	2.31	3/8	40S	0.86
17.15	3.20	3/8	80S	1.12
21.34	2.11	1/2	10S	1.02
21.34	2.77	1/2	40S	1.29
21.34	3.73	1/2	80S	1.65
26.67	2.11	3/4	10S	1.30
26.67	2.87	3/4	40S	1.71
26.67	3.91	3/4	80S	2.23
33.40	2.77	1	10S	2.13
33.40	3.38	1	40S	2.54
33.40	4.55	1	80S	3.29
33.40	6.352)	1	160	4.30
42.16	2.77	1¼	10S	2.73
42.16	3.56	1¼	40S	3.44
42.16	4.85	1¼	80S	4.53
42.16	6.352)	1¼	160	5.69
48.26	2.77	1½	10S	3.16
48.26	3.68	1½	40S	4.11
48.26	5.08	1½	80S	5.49
60.33	2.77	2	10S	3.99
60.33	3.91	2	40S	5.52
60.33	5.54	2	80S	7.60
60.33	8.742)	2	160	11.29
73.03	3.05	2½	10S	5.35
73.03	5.16	2½	40S	8.77
73.03	7.01	2½	80S	11.59
88.90	3.05	3	10S	6.56
88.90	5.49	3	40S	11.47
88.90	7.62	3	80S	15.51
88.90	11.132)	3	160	21.67
101.60	3.05	3½	10S	7.53
101.60	5.74	3½	40S	13.78
101.60	8.08	3½	80S	18.92
114.30	3.05	4	10S	8.50
114.30	6.02	4	40S	16.32
114.30	8.56	4	80S	22.67
114.30	13.492)	4	160	34.05
141.30	6.55	5	40S	22.10
141.30	9.53	5	80S	31.44
141.30	15.882)	5	160	49.87
168.28	3.4	6	10S	14.04
168.28	7.11	6	40S	28.69
168.28	10.97	6	80S	43.21
168.28	14.27	6	120	54.75
168.28	18.262)	6	160	68.59
219.08	8.18	8	40S	43.20
219.08	12.7	8	80S	65.63
219.08	18.23	8	120	91.30
219.08	23.012)	8	160	112.97

Get In Touch

Alloy C276 Uses & Applications

Alloy C276 are widely used all over the world in different industries. Here are the top uses of Alloy C276

Transporting materials: such as hot water, chemicals, oil, gas, and sulfur in various industries.
Automotive industry: air and water flow systems, and piping systems.
Sewerage systems: industrial water lines and water mains. Heating, ventilating, and air-conditioning equipment.
Construction industries: structural applications and scaffolding.
Homes and buildings: supply and exhaust piping, water pipes, and curtain rods.

About Alloy C276

Alloy C276 (UNS N10276) is an austenitic nickel-molybdenum chromium alloy with a small addition of tungsten. It is one of the premier corrosion-resistant materials available for process industries. Alloy C-276 has superior resistance to pitting, stress corrosion cracking, and oxidizing atmospheres. Alloy C-276 can be formed using various cold and hot working processes. Like other nickel alloys, alloy C-276 work hardens quickly, though it can be cold formed using aggressive methods like deep drawing, press forming, and punching

Hastelloy Grades

ADDITIONAL INFORMATION OF ALLOY C276:

Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer), Other
Port of Dispatch: Mumbai OR KALAMBOLI India
Packaging Details:Alloy C276 are given marking, painted with black japan or black Board (Mat Finish) & will be packed in a bagging bag with stickers written with size, grade & quantity.

Manufacturer Supplier of Alloy C276 in India:

We, Nova Steel Corporation are Manufacturers of Alloy C276 in Mumbai, India. Our high-quality range of Alloy C276 is exclusively designed for chemical industries, steel factories, petrochemical industry, fire protection systems, shipping/shipment industries, etc. Alloy C276 are made with precision using the best quality raw material. We also customize Alloy C276 as per the customer’s requirements.
